TEBS E
10
Operation
181
Remote control
unit
446 056 11. 0
Control box
446 156 02. 0
SmartBoard
446 192 11. 0
Remote con-
trol unit
446 056 25. 0
Lifting/Lowering
button
Press simultane-
ously:
Press simulta-
neously:
Save memory level (M1)
Press simultane-
ously:
Press simulta-
neously:
Select memory level (M2)
Press simultane-
ously:
Press simulta-
neously:
Save memory level (M2)
–
1.
2.
–
Activate Standby: Towing vehicle
hitched. Press button within 30
seconds of switching the ignition off.
Trailer level control is active, during
ramp operation for example
1.
Within 30
seconds:
2.
– –
End Standby control > 5 seconds:
– –
Operation of ECAS level control with eTASC
The vehicle can be lifted or lowered by means of simply moving the lever by hand.
As soon as the desired height is reached, the lever will be turned back downwards
(all device variants with exception of ‘Dead Man’).
A height adjusted by means of the lever is controlled by TEBS E and maintained
even with subsequent changes to load, provided the following requirements are
met:
• Ignition turned on or ECAS stand-by time active
• Parameter No level control while stationary deactivated
• ’Level control off’ open
If the lever is operated simultaneously while TEBS E is performing level adjust-
ments, TEBS E will be unable to correctly identify the manual operating request.
Any level adjustments performed by TEBS E should be given time for completion
before the manual level change demand by means of the hand lever.
