Operation CRT 48
4.14 Pitch Adjustment
When changing or setting the pitch (angle) of the trowel blades, slow the machine,
set the desired pitch on the left side of the machine, then adjust the right side to
match.
To increase the pitch, turn the pitch control inward (a). Use the pitch indicator (b) to
adjust pitch equally on both right and left trowel blades.
4.15 Emergency Shutdown Procedure
Procedure If a breakdown or accident occurs while the machine is operating, follow the
procedure below:
1. Stop the engine.
2. Close the fuel valve.
3. Remove the machine from the job site using the wheel kit.
4. Clean concrete from the blades and the machine.
5. Contact the rental yard or machine owner for further instructions.
Working Conditions of
Concrete
Suggested Working
Pitch
1. Wet surface working stage Flat (No Pitch)
2. Wet to plastic working stage Slight Pitch
3. Semi-hard working stage Additional Pitch
4. Hard finishing stage
(burnishing)
Maximum Pitch
5-10º
15º
0°
25°
4
3
2
1
wc_gr000147
a
b
20-25º
