wc_td000188gb.fm
49
CRT 48
Technical Data
7.2
Machine
Machine
CRT 48-
35V
CRT 48-
34V
CRT 48-
31V
CRT 48-
35L
Trowel
Operating weight
kg (lbs.)
508 (1130)
558 (1240)
603 (1340)
Dimensions (L x W x H)
mm
(in.)
2566 x 1295 x 1473
(101 x 51 x 58)
Rotor speed (range)
rpm
25–165
Blade pitch (range)
degrees
0–25
Gearbox
type
Heavy duty, fan cooled
Gearbox lubrication
type
Mobil Glygoyle 460
l (oz.)
1.83 (62) each
Driveshaft
type
Splined universal joint
Operation
Troweling width
with pans
(non-overlapping)
without pans
(non-overlapping)
mm
(in.)
2465 (97)
2413 (95)
Troweling area
with pans
(non-overlapping)
without pans
(non-overlapping)
m
2
(ft
2
)
3 (32)
2.8 (30)
48
50
Table of Contents
