wc_tx001542gb.fm
74
Schematics CRT 48
10.6 CRT 48-34V and CRT 48-31V—Electrical Schematic Components
Ref. Description Ref. Description
A Battery U Spray pump motor
B Oil pressure switch (dual circuit) V Engine connector
C Fuel pump W Fuel cut-off solenoid
D Fuel pump relay X Starter motor
E Key switch Y Engine crank solenoid
F Hour meter Z Glow plug fuse
G Oil pressure indicator light AA Relay—safety system
H Operator presence switch
(normally open)
BB Voltage regulator
J Throttle sense switch
(normally closed)
CC Alternator
K Neutral relay DD Glow plug temperature sensors
L Right front light EE Glow plugs
M Right rear light FF Keyed power fuse
N Left rear light GG Temperature sensor
O Left front light HH Coils—ignition
P Fuse—spray system JJ Ignition module
Q Fuse—main KK Engine speed sensor
R Fuse—light circuit LL External voltage regulator
(Honda engines only)
S Light switch MM Glow plug relay
T Spray pump switch
