CRT 48 Maintenance
5.8 Blade Arm Adjustment
To eliminate wobble:
1. Pitch the blades flat.
2. Tighten lock nut located at the bottom of each pitch cable. Maximum cable play
should be no more than 3.18 mm (.125 in.) or the width of the cable.
3. Set gap on all adjustable links to 4.58 mm (.180 in.).
5.9 Mounting Float Pans
Overview Certain applications may require the use of float pans (a). Optional float pans are
available from your Wacker Neuson dealer.
Procedure Follow the procedure below to mount the float pans.
1. Stop the engine.
2. Lift the trowel to access the blades. (See Lifting The Machine.)
3. Position each pan against the blades, and turn the pans either left or right to
engage clip angles (b) as shown.
Note: Right-hand trowel blades turn counter-clockwise; left-hand trowel blades turn
clockwise.
Mounting a
smaller pan
The blade arms on the CRT 48 are designed to accommodate either a standard
48" lip-style float pan or an optional smaller 46” pan. An alternative set of blade
mounting holes (c) is provided for mounting a 46” pan.
wc_gr000275
wc_gr007281
c
d
e
