DPU 130Le 5 Structure and function
Operator's manual
38
The thermally insulated muffler discharges the exhaust gases in a forward
direction.
The glowplugs are preheated for automatic starting of the drive motor. The speed
of the drive motor is controlled via a solenoid. The engine is turned off via an
electrically controlled solenoid valve on the fuel filter.
The electronic control and operator's controls are located in the wiring box.
The maintenance-free battery is located under the remote control holder and
coiled helix cable.
The machine is controlled by remote control only.
