9 Maintenance
87
100_0202_mt_0004.fm
9.2.8 Checking hydraulic oil level and refilling hydraulic oil
Performing preparations
1. Place the machine upright on a flat surface.
2. Open both protective hoods.
3. Deactivate the machine.
4. Let machine cool off.
Checking the hydraulic oil level
X Check if the hydraulic oil reaches the middle of the oil level glass.
Item Designation
1 Hydraulic oil tank cap
2 Oil level glass
