6 Components and operator's controls DPU 130Le
45
Operator's manual
Slow/fast operation button
Use the Slow/fast operation button in order to switch between slow and fast
operation. Fast operation is turned on by default.
Fast operation – compaction operation.
Slow operation – operation with reduced engine speed to traverse highly
compacted surfaces or hard substructures.
Stand vibration button
If you hold the Stand vibration button, the machine will compact without moving
in any direction.
Carrying belt
The remote control can be hung on the carrying belt.
Battery
The battery supplies the remote control with power.
The battery can be charged with the machine's coiled helix cable or the external
charger (accessories).
Control lamps
Charging
The Charging control lamp is lit in green when the battery is charging.
The Charging control lamp extinguishes when the battery is charged.
Operation
The Operation control lamp flashes green when the remote control is turned
on.
The Operation control lamp will extinguish once the remote control is turned
off.
The Operation control lamp flashes red when the battery is low.
The Operation control lamp is lit in red when the battery is discharged.
Diagnostic
The Diagnostic control lamp briefly flashes green when you move a control
lever or press a button on the remote control.
