DPU 130Le 7 Transport
Operator's manual
48
Lifting and transporting machine with forklift
Note: Designate a skilled person to ensure safety during the lifting
procedure.
Note: Only use bearers with a profile no larger than 125 x 50 mm.
The distance between the bearers is 550 mm.
1. Carefully insert the bearers into the forklift support until they lock into place.
2. Angle the bearers in the direction of the forklift so that the machine cannot
slide down during lifting.
3. Lift the machine evenly with the forklift.
4. Carefully set the machine down on a suitable transport vehicle.
Item Designation
1 Forklift support
2 Bearers
