Maintenance 7
Position Lubrication point Interval Quantity
1 3-pin pivot plate Daily 2
2
Shovel arm Daily 3
3
Bucket cylinder Daily 1
4
Stick cylinder Daily 2
5
Boom Daily 2
6
Triple articulation boom cylinder Daily 4
7
Swiveling console Daily 2
8
Boom cylinder Daily 2
9
Swiveling cylinder Daily 2
10
Triple articulation boom Daily 1
11
Live ring teeth (authorized service center) 1
12
Live ring (ball bearing)
– see chapter “ Live ring (ball bearing)” on page 7-15
Daily 1
13
Stabilizer blade Daily 4
14
Remote lubrication point stick cylinder Daily 1
