BA E14 track en* 1.3 * E14t_13_400.fm 4-27
Putting into operation 4
Protective Front Guard structure category II (option)
Danger of piercing/penetration by objects from the front!
Causes serious injury or death.
► Install a protective Front Guard structure in areas with danger from the
front (for example pipes, tree trunks).
The protective Front Guard structure corresponds to category II according
to ISO 10262:1998.
► The vehicle owner must ensure that the hazard situation is evaluated
and that the national regulations are observed.
► The vehicle owner must ensure that only work is performed that does
not require any higher protection.
► Accidents cannot be fully avoided despite equipping a vehicle with
protective structures.
1. Stop and park the vehicle. Stop the engine. See “Preparing lubrication”
K: mounting points top left and right.
2. Install screws L and lock nuts M and tighten to 110 Nm (81 ft.lbs.).
Fig. 122
Fig. 122 (symbolic representation)
