4 Putting into operation
3. Place the FOPS screen on the cabin roof.
E: mounting points for brackets B left and right.
4. Install screws F and tighten them to 45 Nm (33 ft.lbs).
G: mounting points at the front left and right.
5. Install screws H and lock nuts J and tighten to 110 Nm (81 ft.lbs.).
6. Put caps on all screws and nuts.
Information
If the vehicle is equipped with air-conditioning, point 2 does not apply. The
housing of the air-conditioning system is equipped with mounting
bushings for the rear screws.
A: housing version 1
B: housing version 2
Fig. 118Fig. 118
Fig. 119Fig. 119
E
F
Fig. 120
Fig. 120
G
H
Y
Fig. 121
Fig. 121
A
B
