BA E14 track en* 1.3 * E14t_13_710.fm 7-51
Maintenance 7
Adding hydraulic oil
Slipping/tripping hazard when adding hydraulic oil!
Can cause injury.
► Use a safety-oriented ladder to add hydraulic oil.
► Do not use vehicle parts or attachments as a climbing aid.
1. Open valve cover B.
2. Open breather filter C slowly to release the pressure inside the
hydraulic oil reservoir.
3. Remove breather filter C.
4. Add hydraulic oil up to the corresponding mark.
5. Check the hydraulic oil level on sight glass A.
6. Add if necessary and check again.
7. Screw in breather filter C tightly.
8. Close and lock valve cover B.
Use a suitable container to collect fluids and lubricants as they flow out
and dispose of them in an environmentally friendly manner.
