BA E14 track en* 1.3 * E14t_13_400.fm 4-25
Putting into operation 4
Protective FOPS structure category II (option)
Crushing hazard due to falling objects!
Causes serious injury or death.
► Install a protective FOPS structure for vehicle operation in areas with
danger of falling objects.
The protective FOPS structure corresponds to category II according to
ISO 10262:1998/EN ISO 3449:2008.
► The vehicle owner must ensure that the hazard situation is evaluated
and that the national regulations are observed.
► The vehicle owner must ensure that only work is performed that does
not require any higher protection.
► Accidents cannot be fully avoided despite equipping a vehicle with
protective structures.
1. Stop and park the vehicle. Stop the engine. See “Preparing lubrication”
A: mounting points rear left and right (for vehicles without air conditioning
system).
2. Install brackets B with screws C and lock nuts D and tighten to
65 Nm (48 ft.lbs).
Fig. 116Fig. 116 (symbolic representation)
