9-2 BA E14 track en* 1.3 * E14t_13_900.fm
9 Technical data
Engine
1
ET65 Tier IV
Manufacturer Perkins
Type 404F-E22TA
Design Water-cooled 4-cylinder diesel engine
Intake system Turbo-charging, charge air cooling
fuel injection system Direct
Engine management Electronic
Displacement 2216 cm
3
(129 in
3
)
Nominal bore and stroke 84 mm x 100 mm (3.3 x 4 in)
Rated output at rated speed
50 kW at 2800 min
-1
(67.1 hp at 2800 rpm)
Engine power at preset maximum engine speed
ECO
39.2 kW at 1800 min
-1
(52.6 hp at 1800 rpm)
PWR
43.5 kW at 2000 rpm
(58.3 hp at 2000 rpm)
Max. torque
208 Nm at 1800 rpm
(153 ft.lbs. at 1800 rpm)
Max. engine speed without load 2000 rpm
Lower idling speed 1200 min
-1
(rpm)
Preheating system Glow plugs
Exhaust-gas treatment Diesel oxidation catalyst
Exhaust values according to
EU NRMM 97/68/EC Level 3B
US EPA 40 CFR Part 89 Tier IV final
1. Output values can vary by +/- 5 %.
