9-10 BA E14 track en* 1.3 * E14t_13_900.fm
9 Technical data
Fuse Relays Protected circuits
F001 K001 12 V 15-1
F002 -- Fuel-filling pump
F003 -- 12 V 30-1
F004 -- Air-conditioning fan
F004 -- Air-conditioning fan
F005 -- Air-conditioning fan
F010 -- Engine control unit
F011 -- Engine control unit
F012 -- Not assigned
F013 -- Engine control unit
F014 K088, K089 Fuel pump, DPF pump
F015 K90 DPF glow plug (ET90: cable bridge)
F016 K7 Starter terminal 50
F020 -- Control valve TTC 77
F021 -- Control valve TTC 30
F022 -- Control valve
F023 K114 Rotating beacon, radio, Telematic
F024 -- 12 V connection
F025 -- Not assigned
F027 K048 Working light on chassis
F028 K049 Roof light
F029 -- Not assigned
F030 -- Control terminal 15
F031 -- Heated seat
F032 K023 Wiper
F033 K108, K130 Hydraulic valves, horn, air-suspension comfort seat
F034 -- Traveling drive (not assigned)
F036 K011 Heating, air conditioning
F037 K047 Boom working light
F038 -- IO controller IO, starter
F040 -- Not assigned
F041 -- Not assigned
F042 K062 Not assigned
F043 K063 Not assigned
-- K010 Not assigned
-- K005 Preheating
-- K002 Main relay
