Wacker Neuson ET65 - Page 349

BA E14 track en* 1.3 * E14t_13_900.fm 9-65
Technical data 9
ET90 (triple articulation boom)
Dimensions
mm (in)
A Height 2562 (8'-5'')
B1 Cabin width 1000 (39)
B2 Upper carriage width 2017 (79)
B3
Travel gear width 2250 (89)
1
Wide travel gear (steel chain 600mm/24 in) 2400 (95)
C1 Transport length with stabilizer blade (short stick) 6468 (21'-3'')
C2 Transport length with stabilizer blade (long stick) 6690 (21'-11'')
D1 Max. digging depth (short stick) 4379 (14'-4'')
D2 Max. digging depth (long stick) 4679 (15'-4'')
E1 Max. vertical digging depth (short stick) 3198 (10'-6'')
E2 Max. vertical digging depth (long stick) 3456 (11'-4'')
F1 Max. digging height (short stick) 7931 (26'-0'')
F2 Max. digging height (long stick) 8196 (26'-11'')
G1 Max. tilt-out height (short stick) 5674 (18'-7'')
G2 Max. tilt-out height (long stick) 5940 (19'-6'')
H1 Max. reach at ground level (short stick) 7463 (24'-6'')
H2 Max. reach at ground level (long stick) 7751 (25'-5'')
K1 Max. digging radius (short stick) 7596 (24'-11'')
K2 Max. digging radius (long stick) 7889 (25'-11'')
M Max. boom displacement to bucket center (right side) 705 (28)
N Max. boom displacement to bucket center (left side) 683 (27)
O Max. lift height of stabilizer blade over ground 479 (16)
P Max. scraping depth of stabilizer blade below ground surface 518 (20)
Q1 Distance between bucket and stabilizer blade (short stick) 567 (22)
Q2 Distance between bucket and stabilizer blade (long stick) 441 (17)
R1 Min. tail end swiveling radius 1583 (62)
R1 Min. tail end swiveling radius with rear weight 1655 (65)
R2 Boom swivel radius (center) 2840 (9'-4'')
R3 Boom swivel radius (right) 2759 (9'-1'')
R4 Boom swivel radius (left) 2280 (90)
S Total running gear length 2826 (9'-3'')
T Running gear length (Turas front idler) 2233 (88)
W1 Max. tilting angle of boom to the right 63°
W2 Max. tilting angle of boom to the left 67°
X
Track width 450 (18)
Chain width (option) 600 (24)
Y Stabilizer blade width 2250 (89)
1
Z Stabilizer blade height 501 (20)
1. From serial no. WNCE1404EPAL00160 to serial no. WNCE1404PPAL00180: 2200 mm (87 in)
