Wacker Neuson ET65 - Page 53

BA E14 track en* 1.3 * E14t_13_300.fm 3-11
Introduction 3
Meaning
Crush Hazard
1. Use the handholds for opening and closing the front window.
2. Lock the window into place.
Position
On the window wiper motor
Meaning
Accumulator is under high pressure. Maintenance or repair work may be
performed only by a Wacker Neuson service center.
Position
Under the valve cover
Meaning (option)
Emergency exit if equipped with Front Guard option
Position
Inside the cabin on the rear window
Meaning (option)
Injury hazard due to grease escaping under pressure
Read the operator’s manual before working with the track tensioner.
Position
On left and right-hand undercarriage
Meaning (option)
Load diagram
Position
On the headliner
Fig. 17
Fig. 18
1000264714375-5050
Fig. 19
Fig. 20
Fig. 21
