BA E14 track en* 1.3 * E14t_13_300.fm 3-17
Introduction 3
Meaning
Cabin relays and fuses (A)
Engine compartment relays and fuses (B)
Position
A: on the outside of the fuse box cover.
B: on the partition wall in the engine compartment
Meaning (option)
Operating procedures differing from the ISO controls if the SAE controls
are set.
Position
On the roof window on the right
Meaning
Battery master switch
Position
At battery master switch
Fig. 36 (symbolic representation)
B
A
Fig. 37
Fig. 38
