Wacker Neuson ET65 - Page 75

BA E14 track en* 1.3 * E14t_13_400.fm 4-7
Putting into operation 4
Integrated rain shield
When the entire front window is open, the lower front window can be used
as an additional means of protection against rain.
Information
The rain canopy cannot be used when the Front Guard is mounted.
Open
1. Press and hold levers C on the left and right, and push the front
window all the way forward.
2. Pull the front window backward with handles D on the left and right
until it engages.
Close
1. Press levers C on the left and right and pull the front window backward.
2. Release levers C and pull the window all the way backward until it
engages.
Opening/closing the side windows
Both side windows on the right can be opened.
Open
Press lever A and let the side window engage in the required recess.
Close
Press lever A and close the side window.
Fig. 83
Fig. 84
C
D
Fig. 85
A
A
