WAGNER EPG-Sprint X Original Service Manual

11
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
3 IDENTIFICATION
3.1 EXPLOSION PROTECTION IDENTIFICATION IN ACCORDANCE WITH ATEX
The device is suited for use in potentially explosive areas, in accordance with Test Certi cate
PTB 06 ATEX 5003 (EPG-SPRINT) or PTB 12 ATEX 5001 (EPG-SPRINT X/EPG-SPRINT XE).
0102
II 3(2)D IP 64 80 °C
CE: European Communities
0102: Number of noti ed body which issues the recognition of quality assurance in
production.
Ex: Symbol for explosion protection
II: Device class II
3: Category 3 (Zone 22)
(2): Impact on equipment of category 2
D: Ex-atmosphere dust
IP64: Protection class 64
80 °C: Temperature class: maximum surface temperature < 80 °C; 176 °F
3.2 PERMISSIBLE DEVICE COMBINATIONS
The following powder spray guns may be connected to the EPG-SPRINT/EPG-SPRINT X/
EPG-SPRINT XE:
Manual spray guns
– Corona spray gun PEM-X1, PEM-X1 CG, PEM-C3, PEM-C4,
PEM-C4-Ergo
– Tribo spray gun PEM-T3
Automatic spray guns
– Corona spray gun PEA-C3, PEA-C4
– Corona spray gun PEA-C3XL, PEA-C4XL
– Tribo spray gun PEA-T3
– Tribo spray gun PEA-T3XL
Only EPG-SPRINT X/EPG-SPRINT XE (starting from software version 212)
– Tribo lance TL1
Older or other gun types may only be connected to the control unit after  rst checking
their suitability with WAGNER.
Permissible device combinations for the USA and Canada, see Chapter 17.7 "FM Approval".
