The comparison measurement should be within 0.2 m³/h of the limit position. If the
values are too far apart or once a valve has been replaced, the device can be recalibrated
(see parameter C42, chapter 10.4).
7. Pressing the "Standby" button 15 stops the test; the unit is then in standby mode.
9.2 PARAMETER C34, I/O TEST (INPUT AND OUTPUT)
Purpose:
– To test the electrical inputs and outputs
Note:
A manual gun and CCM 2007/CCM Prima control unit are needed to test the parameter.
Procedure:
1. Access parameter C34 (refer to Chapter 8.3 for procedure).
2. Press the "Characteristic Slope" button 31. "no" is displayed on LED display 19.
3. Turn Universal rotary controller 24 one step clockwise. "lot" is displayed in LED
display 19.
4. Press "Additional Recipes" button 25 for 1 second. The display brie y goes out as a
con rmation that the I/O test is now activated.
The ground monitoring and gun trigger signals can be displayed at the gun input.
5. Connect manual gun. Ground monitoring allows the LED bar 1 (kV) to light up.
6. Press gun trigger (no high voltage is produced). LED bar 2 (μA) lights up.
