WAGNER EPG-Sprint X Original Service Manual

40
EPG-SPRINT / EPG-SPRINT X
P_01286
3 2 1
4 65
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
6.2 EPGSPRINT CONTROL UNIT
Pos K Stk Order No. Designation
1 1 2304361 Front display
2 1 2304462 Rotary knob for cover, gray
3 1 2304461 Rotary knob
4 1 2310722 EPG-SPRINT rear panel print complete with sensor hoses
5 1 2304487 Print connection cable
6
3 2311873 WAGNER proportional valve with O-ring
Wearing parts
Not part of the standard equipment, but available as a special accessory
Up to unit serial number 1119, a round valve body is  tted. This can be replaced with the valve with
order number 2311873.

WAGNER EPG-Sprint X Specifications

General

Brand	WAGNER
Model	EPG-Sprint X
Category	Control Unit
Language	English
