WAGNER EPG-Sprint X Original Service Manual

71
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
8. Switch o the input pressure to vent the system.
9. Press "High-voltage" button 27 to access step 2.
Step 2:
The dosing air valve is opened and the system's residual air is blown out.
10. Press "High-voltage" button 27 to access step 3.
Step 3:
Both valves are closed and the test completed.
10.4 PARAMETER C42, CALIBRATING AIR OUTLETS
Purpose:
– To calibrate the electronic  ow measurement for any air outlet
Note:
The accuracy of the measuring unit is critical and can also impair the calibration result if
necessary.
Calibration is only recommended if one or more valves are replaced.
The  rst step is to check the accuracy with function C31. If a major deviation is found,
calibration with function C42 is required.
