WAGNER EPG-Sprint X Original Service Manual

72
EPG-SPRINT / EPG-SPRINT X
P_01274
Tribo Corona
5
4
3
2
1
120
100
80
60
40
30
20
15
10
5
μA
μA
2x
kV
90
80
70
60
50
40
30
20
10
100
P_01271
24
19
16
15
312927
25 25
EPG
SPRINT X
0
%
kV
80
60
40
20
100
Tri Cor
5
4
3
2
1
120
80
40
20
10
2.0
μA
P_01830
24
19
16
15
312927
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
Procedure:
1. Access parameter C42 (refer to Chapter 10.2).
2. Press the "Characteristic Slope" button 31. "no" is displayed on LED display 19.
3. Turn Universal rotary controller 24 one step clockwise, "AFA" is indicated in the LED
display 19.
4. Press "Additional Recipes" button 25 for 1 second. The display goes out brie y as a
con rmation.
5. In step 0 (no LED is lit in the "High-voltage" LED display 1), the desired air channel
can now be selected by pressing the "Characteristic Slope" button 31.
Atomizing air Dosing air Feed air
6. The "High-voltage" button 27 and "Current Limitation" button 29 can now be used
to select the following 9 steps.
