WAGNER EPG-Sprint X Original Service Manual

73
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
Step Display Description Possible values
1 e.g., 263 High-gain o set is determined automatically. 200-700
2 e.g., 23 Low-gain o set is determined automatically. 2-100
3 0.0-100% Turn rotary controller 24 clockwise until 1.00 m³/h is
displayed on the external measuring device.
Con rm the value by pressing "Additional Recipes"
button 25 for approx. 1 second. The system jumps to
step 4.
External measuring device
1.00±0.1 m³/h accurate
4 Control operation for checking the range between
0 - 1.00 m³/h. If the display is imprecise, use "Current
Limitation" button 29 to return to step 3.
5 0.0-100% Turn rotary controller 24 clockwise until 4.00 m³/h is
displayed on the external measuring device.
External measuring device
4.00±0.1 m³/h accurate
Con rm the value by pressing "Additional Recipes"
button 25 for approx. 1 second. The system jumps to
step 6.
6 Control operation for checking the range between
1-5.00±0.1 m³/h. If the display is imprecise, use "Current
Limitation" button 29 to return to step 3.
7 e.g., -13 High gain correction factor [after reset = 0] ±99
8 e.g., -3 Low-gain correction factor [after reset = 0] ±99
9 End The new values are saved to the memory.
Note:
All nine steps must be selected to successfully complete this process.
7. Press "Standby" button 15 to exit the con guration.
