WAGNER EPG-Sprint X Original Service Manual

65
EPG-SPRINT / EPG-SPRINT X
P_01669
kV
80
60
40
20
100
Tri Cor
5
4
3
2
1
120
80
40
20
10
μA
P_01758
3 4
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
Test of gun remote control:
(only for manual gun PEM-X1 in conjunction with EPG-SPRINT X or EPG-SPRINT XE control unit)
7. If the remote control button "Powder +" is pressed, the "Corona" LED 4 lights up.
8. If the remote control button "Powder -" is pressed, the "Tribo" LED 3 lights up.
9. The LED display of the gun remote control  ashes with a bright phase of 250 ms and
a dark phase of 250 ms.

WAGNER EPG-Sprint X Specifications

General

Brand	WAGNER
Model	EPG-Sprint X
Category	Control Unit
Language	English
