Testing the 2 outputs of the CCM bushing for remote control:
1. If the input test functions as described above, the output for pin 4 is  ne.
2. Press "Atomizing Air" button 21; a fault is triggered in the CCM (red lamp lights up).
3. Press "Atomizing Air" button 21 again, then the "Reset" button on the CCM. The fault
is reset on the CCM, the red lamp goes out.
