WAGNER EPG-Sprint X Original Service Manual

89
EPG-SPRINT / EPG-SPRINT X
Pressure regulator 6bar
Main Switch
L N
PE
Power IN plug
1 2
Power OUT plug
L N
PE
1 2
L N
JF3
+24VDC
GND
1 2 3 4 5 6 7 8
JD1
Gun trigger - Tribo current Groundmonitor Gun trigger + not used Coil + Coil - GND/EARTH
Fuse 2 1.6AT
PR
PCB EPG-Sprint X Back
P
PCB EPG-Sprint X Display
Earth connector to lid
Air distribution and regulation
10 pol
2x Fuse FST 5x20 Change from outside
blau/blue
GND
1 2 3 4 5 6
JD2
Fault Out Fault Reset Start/Stop +24VDC GND Recipe select
Schematic SCH-3215C
Erdverbindung zum Deckel
Luftverteilung und Einstellung
#2304460
Druckregler 6bar
9953536
2x Fuse holder FPG1
STASEI200 STAKEI200
Earth / Ground
PP
24V+
Valve1
#2304460 #2304460
Schematic SCH-3214D
9952587 2348276
Relais
26
48
0 A1 1 A2
+24VDC
Spraygun plug
Air main supply 6.5-8bar
Feed air/Förderluft Dosage air/Dosierluft
Atomizing air/Zerstäuberluft
Interlock/Remote
Drucklufteingang 6.5-8bar
Pistolenstecker to CCM
94-116psi
2A slow 9951116
K1 T66
GND
GND
GND
JF4
JF10
JF9
rot/red
Mains power supply EPS45-24
Input: 90-264VAC/47-63Hz Output: 24VDC 1.9A
Fuse FS1 T2.5A soldered on PCB
GND
Phase: braun/brown Neutral: blau/blue
24V+
Valve2
24V+
Valve3
JF1
JF2
JF3
JF4
JF5
JF6
P_03258
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
EPG-SPRINT XE
