WAGNER PEM-C2 - 8 Specification

PEM-C2
8. Specification
Weight: 498 g
Electrical:
input voltage: max. 22 Vpp
input current: max. 0.9 A
frequency: 19 ... 30 kHz
output voltage: max. 100 kV DC
output current:
max. 160 µA DC
polarity: negative
design: according to EN 50050
protection class: IP 54
Pneumatic:
input air pressure (atomizing air): max. 3 bar
powder output volume: max. 450 g/min
Compressed air quality according to ISO 8573.1:
residual water content in compressed air: max. 1.3 g H
2
O/Nm
3
at a dew point of 7 °C
residual oil content in compressed air: max. 0.01 mg oil/Nm
3
residual dust content in compressed air: max. 1 mg dust/Nm
3
Hint
Volume measures:
All volume indications (m
3
/h) are Nm
3
/h. (norm cubic meters per hour). One cubic
meter of a gas at 0 °C and 1.013 bar is called norm cubic meter.
1 Nm
3
/h = 35.3 ft
3
/h
Ambient conditions:
If low temperature powders are used, the ambient temperature may have to be lower than
30 °C.
02/01 21 0351801
