WAGNER PER-X1 - PER-X1 Corona Robot Spray Gun with a Round Jet Nozzle

Operating manual Robot powder spray gun PER-X1
13 Spare Parts
60 Order number 2444998 | Edition 10/2022
13.4 PER-X1 CORONA ROBOT SPRAY GUN WITH A ROUND JET NOZZLE
1
4
6
7
P_04909
5
9
2
3
Pos K Stk Order no. Designation
1 1 2423084 * Corona robot spray gun, PER-X1
2 ♦ 1 SeeAcces-
sories [851]
Connection cable, PER-X1
3 1 2434666 Handle, complete
4 1 2320464 Union nut, X1
5 ♦ 1 2322493 Electrode holder, X1 R, with nozzle
6 ♦ 1 2429695 Replacement protective wedge, X1
7 1 2324205 Wedge tool, X1
11 6 m 9982079 Hose, black, Ø 6 mm
* = Standard version with flat jet nozzle. For versions with round jet nozzles, pos. 5 must be
ordered separately!
