Oil Pressure Warning Horn
The oil pressure warning horn indicates that engine
oil pressure is below the safe operating level
[below 3 to 5 PSI (21 to 34 kPa)]. The horn is
located inside the chassis as shown in Warning
Horn Location photo. This horn will sound when
the ignition is turned ON, but should go o after the
engine is started. If the horn fails to sound when
the ignition switch is turned ON, it could indicate a
horn failure. If the horn sounds during engine
operation, stop the engine immediately and correct
the source of the problem before further engine
operation.
IMPORTANT: Continued operation of the engine
with a low oil pressure condition WILL cause
severe engine damage.
Oil Pressure
Warning Horn
Warning Horn Location
Seat Panel Latch
The seat panel hinges forward for maintenance
access and is latched down in the OPERATING
position. To raise the seat panel, move the latch
release backward.
Seat Panel Latch
Seat Panel Latch
Parking Brake
The parking brake functions by locking a detent
arm to a cog in the hydraulic motor rotor. Moving
the lever FORWARD engages the parking brake;
moving the lever BACKWARD releases the brake.
IMPORTANT: Stop the tractor completely before
engaging the parking brake. The parking brake
uses a positive mechanical lock similar to the
PARK position on an automotive automatic trans-
mission. If the tractor is moving when the brake is
engaged, it will result in sudden stoppage and
possible internal damage to the transaxle.
NOTE: If pressure on the parking brake (e.g.,
parked on a hill) makes it impossible to release the
parking brake with the parking brake lever, move
the mower gently forward or backward to allow the
brake detent to release.
Engaged
Position
Parking Brake Engaged
Disengaged
Position
Parking Brake Disengaged
