SAFETY, CONTROL, AND INSTRUCTION DECALS
Safety, Control, and Instruction Decals are installed on the machine;
if any are missing, illegible, or damaged, a replacement should be ordered and installed before
putting the machine into operation. The Decal Part Number is listed below and in the Parts Manual.
8600-4
1.
2.
Location: Seat Panel Cover Plate
Part Number: 8600-4
1. Warning – rotating impeller is a cutting/dis-
memberment hazard to ngers and hands.
● Never reach down into the blower
discharge chute.
2. Warning – thrown object hazard.
● Never engage the PTO with grass catcher
raised.
Location: Rear of Grass Catcher Exhaust Screen
Part Number: 5869
Location: Catcher Door Hinge Bar,
LH and RH Sides
Part Number: 8600-10
Caution - Pinch point.
● Keep all body parts clear when closing grass
catcher door.
8600 -12
Location: Top of Fuel Pump Module Cover
Part Number: 8600-12
Warning – carbon monoxide (CO) poisoning
hazard.
● CO emitted by a running engine can be deadly.
● Do not operate indoors or in other enclosed
areas.
8600-9
60 lb·ft (81 N·m)
Location: Gearbox Cover
(Gear-Driven Decks Only)
Part Number: 8600-9
Tighten blade nuts on gear-driven decks to
60 lb·ft (81 N·m).
9804-1
Location: Chassis Member Behind Transaxles
Part Number: 9804-1
Neutral Lock
● Lift and move into slot to unlock transmission
and allow machine to freewheel.
Location: Front of Catcher Support
Part Number: 5855
