Chapter 5
20
UPC-E AND UPC-E SUPPLEMENT SETTINGS
UPC-E (Universal Product Code-E) is fixed length and is a compressed six digit code used for marking small packages, including
magazines and paperback books. UPC-E symbols are UPC-A symbols that have been zero suppressed (i.e. consecutive zeros are not
included in the symbol).
The printed value of the UPC-E code is a twelve digit code. The nominal height for the UPC-E barcode is one inch. The reduced size is
80% of the nominal size.
UPC-E Enable *
Send Leading Digit *
Send Check Digit *
UPC-E Disable
Do Not Send
Leading Digit
Do Not Send
Check Digit
Expand to UPC-A
On
Expand to UPC-A
Off *
UPC-E Supplement
This option enables the two and five digit supplements for the UPC and EAN/JAN barcode symbologies.
5 Digit Supplement
Enable
2 Digit Supplement
Enable
Transmit if Present
5 Digit Supplement
Disable *
2 Digit Supplement
Disable *
Must Be Present *
*Default
