ENCORE
®
700 METERING PUMP
General Information
To provide satisfactory service, the metering pump must be installed in
accordance with the instructions that follow. Operational difficulties, lack
of accuracy, and possible damage to the pump mechanism may occur if
these instructions are not followed properly.
Unpacking
When the pump is unpacked, check all items against the packing list
to make sure that no parts are discarded with the packaging material.
Whenever possible, unpack the equipment at the installation site.
Mounting the Pump
Pump location is important to the operation of the pump. Select a place
that is dry and that provides a level base for the pump. Allow work space
around the pump for inspection, adjustments, and servicing (refer to
Dwgs. 440.400.110.010 or 440.400.110.020). Be sure it is near a power
supply and located where the discharge line may be conveniently run to
the point of application. The pump may be installed with a floodedsuction
arrangement (refer to Dwg. 440.400.110.040). A carefully considered
and correct installation will help provide satisfactory performance.
When installing the equipment, proceed as follows:
a.
Select the appropriate dimension and/or installation drawing to be
sure th
e location selected will meet all requirements. Refer to Dwgs.
440.400.110.010, 020, 030, an
d 040.
b.
Mount the pump on the bench, shelf, or level pad on which it will be
located.
c.
Connect to a power supply matching the characteristics specified on
the motor n
ameplate and in accordance with local electrical code
requirements. Sufficient flexibility must be provided in the connec-
tion to permit adjustments. Be sure to provide a shut-off switch in
th
e power supply.
NOTE: Field wiring must conform to local electrical codes.
WARNING: TO AVOID POSSIBLE SEVERE PERSONAL INJURY OR DAMAGE
TOTHE EQUIPMENT CONSULT YOUR WPS REPRESENTATIVE IF THE
PUMP IS TO BE USED UNDER CONDITIONS OTHER THAN ORIGINALLY
SPECIFIED AND IF THERE IS ANY QUESTION REGARDING
THE SIZE OF
THE DISCHARGE LINE.
WT.440.400.001.UA.IM.1012
16
