ENCORE

700 METERING PUMP

Preparation for Operation

Fill the solution container with solution.

WARNING: TO AVOID POSSIBLE SEVERE PERSONAL INJURY, USE EX-

TREME CARE TO AVOID CONTACT WITH THE MATERIAL. CONSULT

YOUR CHEMICAL SUPPLIER FOR INSTRUCTIONS IN THE PREPARATION

OF SOLUTIONS AND THE HANDLING OF CHEMICALS.

NOTE: Unless otherwise indicated, drawings referenced in this sec-

tion are located in Section 5.

Remove the plug on top of the gearbox and replace it with breather

cap (26, Dwg., 440.400.001.020A).

NOTE: The pump is shipped with the gearbox already filled with

enough oil. However, checking the oil level at this time is an added

precaution.

CAUTION: To avoid possible severe damage to the pump mecha-

nism, do not run the pump without the gearbox filled with oil.

The oil level must be up to the oil check hole.

Refer to Table 1.3 (in Section 1) to identify the belt location on the

pulley to obtain the desired feed rate. Pumps delivered from the fac-

tory will have the belt located on the first step (top step of the pulley),

which is the maximum speed setting. Install the belt guard before

operating the equipment.

WARNING: TO AVOID POSSIBLE SEVERE PERSONAL INJURY, DO NOT

RUN THE PUMP WITH THE BELT GUARD REMOVED.

Start the motor and operate the pump at a stroke setting of 100%

of the scale until it is primed and ready for operation. The pump is

designed to self-prime under a no backpressure condition; however,

if difficulty is encountered in priming, check that the suction valve is

not adhering to the suction valve seat. Refer to Section 4 - Service if

the pump does not prime.

Starting and Stopping the Pump

Turn the power supply to the pump on or off as needed.

WT.440.400.001.UA.IM.1012
