ENCORE
®
700 METERING PUMP
INTRODUCTION
This manual provides installation, operating, and maintenance instructions
for the Encore® 700 Diaphragm Metering Pumps,
here in after referred
to as the "pump" or "metering pump". The pump
provides accurate
metering and transfer of a wide variety of chemicals.
It is available in
six head sizes, three gear ratios, direct and pulley drive configurations,
and a single or double simplex configuration. A non-loss-
of-motion
stroke adjustment is used to vary the stroke for a smoother
pumping
action. Non-loss-of-motion is achieved through the use of a
variable
eccentric mechanism. Stroke adjustment is accomplished either
manually or with an optional electric stroke length positioner.
An optional Silicon Control Rectifier (SCR) controls drive motor speed
variations through a signal received from an external source.
When an electric stroke length positioner and/or variable speed drive
is used with the pump, a separate instruction manual for each will be
furnished.
W A R N I N G: TO AVOID POSSIBLE SEVERE PERSONAL IN-
JURY OR DAMAGE TO THE EQUIPMENT, THIS EQUIPMENT
SHOULD BE INSTALLED, OPERATED AND SERVICED ONLY
BY TRAINED, QUALIFIED PERSONNEL WHO ARE THOR-
OUGHLY FAMILIAR WITH THE ENTIRE CONTENTS OF THIS
INSTRUCTION MANUAL. WHEN DEALING WITH HAZARDOUS
MATERIAL IT IS THE RESPONSIBILITY OF THE EQUIPMENT
USER TO OBTAIN AND FOLLOW ALL SAFETY PRECAUTIONS
RECOMMENDED BY THE MATERIAL MANUFACTURER/SUP-
PLIER. AVOID CONTACTING ELECTRICALLY HOT METER
POSTS AND CIRCUIT BOARD COMPONENTS WHILE MAKING
METER ADJUSTMENTS.
NOTE: When submitting correspondence always specify model and
serial number of apparatus.
