ENCORE
®
700 METERING PUMP
KEY NO. LEGACY PART NO. ALT. PART NO. QTY. DESCRIPTION

1
APQ5142
W2T417678
1
Gearbox, Simplex

2
AJA5697
W2T417624
1
Connection, DSplex,

3
AXS3656
W2T11182
8
Cap Scr., M8 x 20, Sock. Hd., 316SS

4
AKG4783
2
Bushing Drive, DSplex (5" and 6-1/2" Liquid End Only)

5
ALI3193
W2T367049
1
Oil Seal, 30 x 55 x 7, BUNA

6
AIC4251
W2T367014
1
Bearing, TPRL, 30 x 62 x 21.25mm

7
AMG3448
W2T367066
1
Bearing, TPRL, 20 x 47 x 15.25mm
8
AHS4651
W2T417611
0
Grease, Sunaplex, #992 EP

9
ATI3247
W2T417689
2
Dowel Pin, 6 x 16, M6
10
AQC3041
W2T417685
0
"Locktite" Sealant, TL-242

11
AUK3561
W2T11169
5
Scr. Cap, M6 x 20, Sock. Hd., 316SS

12
AAA1373
W2T11031
1
Shim (.79mm Thick)

15
AAA1388
W2T11029
2
Shim (.13mm Thick)

17 ALI5148 W2T417649 1 Gearbox, Double Simplex

18
AJA4780
W2T11333
2
O-Ring (156) BUNA-N

20
AMK4076
W2T417656
1
Coupling, Rigid, DSplex

21
ATI3361
1
Key, 8 x 7/63

22
AIC4878
W2T417621
2
Tail Bushing

23
AKG5547
W2T417641
2
Preload Nut

24
ALE4774
W2T11422
2
O-Ring (152) BUNA-N

25
ARQ3426
W2T11452
2
Bearing, Angc, 17 x 40 x 17.5

26
AVM3239
W2T11162
2
Washer, Oversized OD, M8

27
AXS3656
W2T11182
2
Cap Scr., M8 x 20, Sock. Hd., 316SS

28
AIC4016
W2T11368
2
Carrier, Bearing

29
AJE5116
W2T11441
2
Adjuster, Bearing

30
AAA3920
W2T10994
2
Quad-Ring #4141, Auto
OR
AQO4757
W2T11391
2
O-Ring (141) BUNA-N, Manual

31
AKG4860
W2T417639
2
Housing

32
ASG3256
W2T11176
2
Dowel Pin, 20 x 40mm, M6

33
AJE4035
W2T367030
2
Crosshead, Diaphragm

34
ARQ4767
W2T11453
2
O-Ring (138) BUNA-N

36
AMG3442
W2T11378
4
Bearing, TPRL, 35 x 72 x 18.25

37
ARQ5679
W2T417686
2
Conrod

38
AKG4976
W2T11401
2
O-Ring (332) BUNA-N

39
AHS4653
W2T11192
2
Plug, R1/2 Socket Head
40
AAA3797
W2T11137
0
Silicone Grease, Light

42
AAC4634
W2T416779
2
Plug, Socket, Screw R1/8, 316SS

43
AOO4043
W2T11392
2
Label, Str. Adj.

44
AAA3769
W2T11314
2
Warning Label

45
AAA3759
W2T11313
2
Warning Label
t
47
APP5655
W2T11093
2
Breather Cap
NOTES: • PART OF AAA4385 e PART OF AOO4751
PAR
T OF AAA4394
WHEN ORDERING MATERIAL, ALWAYS SPECIFY MODEL AND SERIAL NUMBER OF APPARATUS.
AAA1445 ENCORE
®
700 METERING PUMP - PARTS LIST
Double Simplex Gearbox Assembly
440.400.000.020C
ISSUE 5 1-10
WT.440.400.001.UA.IM.1012
