I 35
Electrochlor Mineral Chlorinator
If the minimum selected pump speed does not meet requirements
the interlocked function is deactivated by the timer during programming
as the speed condition is not satisfied.
Low Flow Condition
Achieved a minimum water flow to allow circulation of pool water and chlorinator
operation, when the default pump speed is not enough to guarantee minimum flow
through the system.
This function is only available for variable speed pumps connected to chlorinator
through a communication cable.
1) If after priming a “no-flow “condition is detected Electrochlor activates “Low Flow”
condition detection mode automatically.
2) Electrochlor activates the pool pump again, this time increasing the programmed
speed to the next higher level. This occurs only when a variable speed pump is
running at Eco or Medium speed.
3) If the “no-flow” condition is detected again, the chlorinator will issue a “no-flow”
condition alarm and stop until the next timer cycle.
4) If there is enough flow, the chlorinator will continue operation until timer cycle has
finished.
5) When pump is turn off, the Low Flow condition mode is deactivated until next cycle.
