Thermo Pro 90 4Technical Data
401
4Technical Data
Heater Operation Thermo Pro 90
12 V 24 V
Approval symbol E1 122R 00 0320 (Heater)
E1 10R 03 6196 (EMC)
Model Water heater with evaporator-type burner
Heat output Max.
Control range
9.1 kW
1.8 to 7.6 kW
Fuel Diesel DIN EN 590
PME DIN EN 14214
Fuel consumption
±10%
Max.
Control range
1.14 l/h
0.21 to 0.92 l/h
Rated voltage 12 V 24 V
Operating voltage range 10.5 to 14.7 V 20 to 29 V
Nominal power consumption with circulation
pump
± 10 % (without vehicle fan)
Max.
Control range
≤ 90 W
37 to 83 W
Perm. ambient temp.:
Heater incl. control unit:
- Operation
- Storage
Metering pump:
- Operation
- Storage
-40 to +80 °C
-40 to +125 °C
(heater off, operating voltage may be connected)
-40 to +30 °C
-40 to +85 °C
Perm. operating gauge pressure (coolant) 2.5 bar
Capacity of the heat exchanger 0.15 l
Max. combustion-air intake temperature +40 °C
Max. fuel temperature +30 °C
Minimum quantity of coolant circuit 6.00 l
Delivery rate of the circulation pump against 0.15
bar
1,650 l/h
CO
2
in exhaust gas (perm. function range) 8 to 13 vol. %
CO
2
adjustment values at approx. +20 °C and
geodetic altitude of 0 m above sea level
10.5 vol. %
Heater dimensions
* From control unit to inlet connection piece of
circulation pump
Also see Fig. 2.
(Tolerance ± 3mm)
L = Length: 355 (381*) mm
W = Width: 131 mm
H = Height: 232 mm
Weight 5.25 kg
