Webasto Thermo Pro 90 - Fig. 902 Replacing Overheating Protection and Coolant Temperature Sensor

Thermo Pro 90 9 Maintaining and Replacing Components
904
Fig. 902 Replacing overheating protection and coolant temperature sensor
1
2
1 = Protective cap
2= Clamp
3 = Overheating protection
4 = Heat exchanger
5 = Round sealing ring
6 = Coolant temperature sensor
3
4
5
6
