Webasto Thermo Top C Installation

Audi A4 / A5
Ident. No.: 1313525D_EN Status: 25.09.2012 © Webasto Thermo & Comfort SE
18
Remove hose on heat exchanger outlet/en-
gine inlet
2 . Spacer bracket 1 and spring clip 3
will be remounted.
Cutting
point
Do not damage coupling piece 3 when cutting
open clamp
2!
1 Discard hose section with protective hose
Removing
coupling
piece
1
Coupling piece on engine inlet
Preparing
hose E
Connect-
ing heater
outlet
27
3 12
28
1 2 3
29
1E
30
D
E
