Webasto Thermo Top C Installation

Audi A4 / A5
Ident. No.: 1313525D_EN Status: 25.09.2012 © Webasto Thermo & Comfort SE
12
1 Cut away tab at marking
2 Cut away bar at marking
3 Remove original vehicle bolt (will be re-
used)
Preparing
installa-
tion loca-
tion
Installing Heater
Insert two washers between bracket 2 and
heater at position
4.
1 Ejot screw [2x]
3 Original vehicle bolt
4 Ejot screw, washer [2x]
Installing
heater
Insert two 5 mm shims between heater and
cross member
1 at position 3.
2 Mount wiring harness of heater
3 Ejot screw, 5 mm shim [2x each]
Installing
heater
17
3
1 2
18
1 1
4
2
3
19
1 2
3 3
