Audi A4 / A5
Ident. No.: 1313525D_EN Status: 25.09.2012 © Webasto Thermo & Comfort SE
Heater/Installation Kit
Foreword
This installation documentation applies to the vehicles Audi A4 / A5 2.7 and 3.0 TDI - for validity, see
page 2 - model year 2008 up to 2011 and later, assuming technical modifications to the vehicle do not
affect installation, any liability claims excluded. Depending on the vehicle version and equipment, mod-
ifications may be necessary during installation with respect to this installation documentation.
However, the stipulations in the "installation documentation", the "operating instructions" and "installa-
tion instructions" for the Thermo Top E / C must always be observed.
The corresponding rules of technology and any information from the vehicle manufacturer should be
observed during the installation work.
General Instructions
Installation should be carried out according to the general, standard rules of technology. Unless spec-
ified otherwise, fasten hoses, lines and wiring harnesses to original vehicle lines and wiring harnesses
using cable ties. Insulate loose wires and tie back!
Sharp edges should be fitted with rub protection (split-open fuel hose).
Spray unfinished body areas, e.g. drilled holes, with anti-corrosion wax (Tectyl 100K, Order No. 111329).
When installing an IPCU, the appropriate settings must be checked and set prior to the installation.
Special Tools
- Torque wrench for 2.0 - 10 Nm
- Hose clamping pliers
- Metric thread-setter kit
- VAS tester (adjustment of Climatronic control unit)
Quantity Description Order No.:
1 Basic delivery scope for Thermo Top E / C See price list
1 Installation Kit for Audi A4 / A5 2.7 / 3.0 TDI with Automatic
Transmission
1313526B
1 Heater control See price list
