Webasto Thermo Top C Installation

Audi A4 / A5
Ident. No.: 1313525D_EN Status: 25.09.2012 © Webasto Thermo & Comfort SE
11
3.0l 150KW / 180 KW
Hose F = 90°, 20x20 mm dia. moulded hose
Discard section
X
A
= 380
B = 90° elbow
C = 115
D = 105
E = 250
Cutting
hoses to
length
2.7l 140KW / 3.0l 176 KW
Hose A = 90° moulded hose, 15x18 mm
Discard section
X
B
= 100
C = 115
D = 105
E = 250
Cutting
hoses to
length
All vehicles
1
27 mm dia. spring clip [2x]
2 20x20 connecting pipe
Premount-
ing hose
Preparing Installation Location
1 7 mm dia. hole [2x]
Drilling
hole in
cross
member
C
X
E
X
D
X
F
B
A
B
X
E
X
D
X
C
X
A
D
15
1
1
2
16
1
155
180
37
1
