Webasto Thermo Top C Installation

Audi A4 / A5
Ident. No.: 1313525D_EN Status: 25.09.2012 © Webasto Thermo & Comfort SE
24
Exhaust Gas
Discard section X
1
Exhaust pipe
a = 210
2 Exhaust end section
b = 260
Preparing
exhaust
pipe
1
Ejot screw
2 Bracket
3 Silencer
4 M6x40 bolt, 30 mm spacer sleeve, flanged
nut
Installing
silencer
1
Hose clamp [2x]
2 Exhaust pipe
Installing
exhaust
pipe
1
Exhaust end section
2 Hose clamp
3 Red (rt) rubber isolator with groove
Installing
exhaust
end sec-
tion
a b
1 2
X
46
2
1
4
3
1
1
2
47
1 2
3
48
