Webasto thermo top evo Workshop Manual

Thermo Top Evo 5 Troubleshooting
505
* WTT = Webasto Thermo Test PC Diagnosis
90 144 Coolant changeover valve
open circuit
The coolant changeover valve
power circuit is open\nor has a
short circuit to +Ub
Conduct electrical test of
coolant changeover valve (see
Section 5.7, Fig. 504,
Point 16)
94 148 Temperature sensor inter-
ruption
Temperature sensor inter-
rupted or short circuit to supply
voltage +Ub
Conduct electrical test of
temperature sensors (see
Section 5.7, Fig. 504, Point 7)
99 153 Glow plug / electronic
ignition unit interruption
Glow plug / electronic ignition
unit interrupted or short circuit
to supply voltage +Ub
Conduct electrical test of
glow plug (see Section 5.7,
Fig. 504, Point 6)
AB 171 Overheat sensor interrup-
tion
Overheat sensor interrupted or
short circuit to supply voltage
+Ub
Conduct electrical test of
temperature sensors (see
Section 5.7, Fig. 504, Point 7)
Fault
code
(HEX)
Fault
code
(DEZ)
WTT* fault message Fault details with double-
click in WTT*
Recommended workshop
action
Fig. 501 Overview of component faults entered in the fault memory
