Weber Summit E-470 - Important Safeguards; Operating the Rotisserie

28
ROTISSERIE BURNER IGNITION & USAGE
IMPORTANT SAFEGUARDS
NOTE: Before using your rotisserie, measure your food at the widest point. If it exceeds
91/2"(241.8mm), it is too large to fit the rotisserie. If it is too large, food can be prepared
using a roast holder and the Indirect Cooking Method.
m WARNINGS
m Read all instructions before using your rotisserie.
m This rotisserie is for outdoor use only.
m Do not expose to rain.
m Do not use rotisserie for any purpose other than its intended use.
m This rotisserie is not for use by children.
m Use heat-resistant barbecue mitts or gloves (conforming to
EN 407, Contact Heat rating level 2 or greater) when operating
barbecue.
m Make sure motor is o before placing it on the motor bracket.
m Remove motor and store in a dry place when not in use.
m Unplug the motor from outlet when not in use, or before cleaning.
m Do not operate the rotisserie motor if it should malfunction.
m Do not operate the rotisserie motor with a damaged cord or plug.
m Do not let power cord hang over any sharp edge or hot surface.
m To protect against electrical hazards do not immerse cord, plug,
or motor in water or other liquids.
m A short cord is supplied to reduce the risk of tripping over the
cord. Extension cords may be used, but caution must be taken to
prevent tripping over the cord.
m If using an extension cord, it must be designed for outdoor use
and rated at 10A/230V.
m When using an extension cord, make sure it is not in contact with
a hot or sharp surface.
m Use the shortest length extension cord possible. Do not connect
two or more extension cords together.
m To reduce the risk of electric shock, keep extension cord
connection dry and o the ground.
m The appliance is to be connected to a socket-outlet having an
earthing contact.
m If any electrical plug adapter is used, it must ground the
appliance.
m Always ensure that the electrical socket being used has the
correct voltage (230 V).
m Failure to follow these warning statements may cause electric
shock, which may result in serious bodily injury or property
damage.
◆
OPERATING THE ROTISSERIE
m WARNING: Set up the rotisserie with food before lighting
rotisserie burner.
A) To set up rotisserie motor, push the button on the retractable rotisserie panel (1). Pull
rotisserie panel upwards. Push locking tab (2) until it snaps into place.
B) Remove power lead and plug into power source.
m CAUTION: Do not route rotisserie motor power lead through the
retractable rotisserie opening in the side table.
m CAUTION: Inspect power lead before each use. If lead
is damaged, do not use. Contact the Customer Service
Representative in your area using the contact information on our
web site. Log onto www.weber.com.
C) Make sure the rotisserie shaft handle is securely fastened. Slide one of the spit forks
towards the right side of the rotisserie shaft, making sure that the spikes face to the
left and the fork screw faces down (3).
D) Push the rotisserie shaft through the center of the food. Insert the tines of both spit
forks into the food. The food should be centered on the shaft. Tighten the spit fork
screw (4).
E) Slide another spit fork onto the rotisserie shaft, making sure that the spikes face to
the right and the fork screw faces up. Insert the tines of both spit forks into the food.
Tighten the spit fork screw (5).
2
1
4
5
3
