Interfaces Description
Table 3.2: Link/Activity LED
State Description
Off No link or equipment not powered.
Solid green With link, no activity.
Blinking With link and with activity.
Table 3.3: Status LED
Color State Description
Green
Off INIT (or not powered)
Alternating on/off PRE-OPERATIONAL.
1 blink and 1 interval SAFE-OPERATIONAL.
Solid green OPERATIONAL.
Red
Off No error (or not powered)
Alternating on/off Interface initialization error.
CFW11 | 9
