WEG SSW-06 Fieldbus Communication Manual

Fieldbus Kit for the Soft-Starter SSW-06
SSW-06 | 6
1 FIELDBUS KIT FOR THE SOFT-STARTER SSW-06
To enable the Soft-Starter SSW-06 for the Profibus DP, DeviceNet, EtherNet/IP or PROFINET communication,
the use of a communication board is required. This communication board is available through an optional kit,
which contains following components:
Table 1: Communication kits for the Soft-Starter SSW-06
Profibus DP-V0 Fieldbus Kit for the Soft-Starter SSW-06 (code 10935570)
Units
Description
Code
1
ABS Profibus DP communication board
10413436
1
Connection cable
10050313
Profibus DP-V1 Fieldbus Kit for the Soft-Starter SSW-06 (code 10935654)
Units
Description
Code
1
ABS Profibus DP-V1 communication board
10413449
1
Connection cable
10050313
DeviceNet Fieldbus Kit for the Soft-Starter SSW-06 (code 10935567)
Units
Description
Code
1
ABS DeviceNet communication board
10413435
1
Connection cable
10413379
DeviceNet Drive Profile Fieldbus Kit for the Soft-Starter SSW-06 (code 10935679)
Units
Description
Code
1
ABS DeviceNet communication board
10413437
1
Connection cable
10413379
EtherNet Fieldbus Kit for the Soft-Starter SSW-06 (code 11169535)
Units
Description
Code
1
ABS EtherNet/IP communication board
11172058
PROFINET Fieldbus Kit for the Soft-Starter SSW-06 (code 14659952)
Units
Description
Code
1
ABS PROFINET IO communication board
14660045
When the communication kit is supplied separately, it must be installed according to the installation instructions
supplied with this kit. When the drive is supplied with already installed communication board, proceed according
to the instruction manual for configuring and operating the equipment on the network.
1.1 COMMUNICATION BOARD INTERFACE
After installation, the communication boards make available connectors, switches and interface LEDs for
operation. In the following section you can find a detailed description of each component.
